Boltless Shelving Standard Sizes

48″ W. x 24″ D. x 72″ H. Boltless Rivet Shelving

Offering an industry-standard 2-foot depth, the 48″ x 24″ x 72″ boltless unit delivers enhanced surface area while maintaining high structural stability under heavier payloads. The 24-inch depth is specifically engineered to hold standard tote boxes, tools, and medium-density warehouse cartons without overhang. Built with heavy-gauge steel corner posts and 4 adjustable levels, this model provides an optimal balance of footprint efficiency and weight-bearing strength for general warehouse staging and retail backrooms.

60″ W. x 24″ D. x 72″ H. Boltless Rivet Shelving

The 60″ wide by 24″ deep configuration expands horizontal storage bay width to accommodate wide cartons, long toolcases, and multi-bin organization systems. With 5 linear feet of open shelf space per level, this 4-shelf unit eliminates center-post obstructions, streamlining dual-sided picking operations. The combination of heavy-duty riveted side beams and particle board decking provides high frame rigidity, making it a dependable choice for industrial maintenance shops and e-commerce order fulfillment hubs.

60″ W. x 36″ D. x 72″ H. Boltless Rivet Shelving

engineered for deep, bulky item storage, the 60″ x 36″ x 72″ bulk shelving unit maximizes cubic capacity without requiring specialized pallet racking. The 36-inch depth allows for double-deep carton staging or oversized equipment containment, making full use of warehouse vertical space. Coated in a protective industrial powder finish, this 4-level unit resists rust and mechanical wear, providing an affordable bulk storage platform for heavy manufacturing components and raw material inventory.

72″ W. x 24″ D. x 72″ H. Boltless Rivet Shelving

Spanning 6 feet in horizontal width, the 72″ x 24″ x 72″ boltless unit provides expansive, unobstructed shelf levels designed for high-volume inventory storage. The 24-inch depth keeps hand-loaded items within comfortable ergonomic reach, while the 72-inch width allows facility managers to store oversized packaging, long retail boxes, and bulky office record archives. Its modular rivet design enables rapid disassembly or vertical shelf re-spacing to match evolving seasonal inventory footprints.

72″ W. x 36″ D. x 72″ H. Boltless Rivet Shelving

The 72″ wide by 36″ deep bulk rivet shelf combines maximum width with deep-deck surface area, providing high-density storage for wide, heavy, and awkwardly shaped goods. Supported by heavy-gauge steel uprights, this 4-level configuration resists frame sway and beam deflection under high uniform distributed loads. It serves as an exceptional bulk storage solution in industrial distribution hubs, military supply depots, and commercial garages requiring maximum storage volume per bay.

96″ W. x 24″ D. x 72″ H. Boltless Rivet Shelving

Extending to an 8-foot wide bay, the 96″ x 24″ x 72″ boltless shelving unit provides continuous horizontal shelf runs designed for long materials, tubing, or multi-carton staging. The boltless rivet connections allow this massive unit to be assembled in minutes without specialized hardware. Supported by 4 heavy-duty particle board shelf levels, this extra-wide configuration reduces the total number of upright posts required along a wall, lowering procurement costs and maximizing usable floor space.

96″ W. x 36″ D. x 72″ H. Boltless Rivet Shelving

The 96″ x 36″ x 72″ model represents a high-capacity bulk rivet storage configuration, merging an 8-foot span with a 3-foot deep deck surface. Engineered to handle large inventory totes, industrial tools, bulk consumer goods, and archive boxes, this unit maximizes warehouse trailer-cubing and staging density. The heavy-duty steel beam framework ensures structural integrity under continuous load cycles, giving warehouses a rugged, cost-effective alternative to heavy pallet racks for hand-loaded inventory.

96″ W. x 48″ D. x 72″ H. Boltless Rivet Shelving

The 96″ wide by 48″ deep by 72″ high boltless shelving unit offers a full 4-foot by 8-foot footprint per shelf level, matching the dimensions of standard industrial plywood and heavy machinery components. Featuring 4 heavy-duty particle board decks, this massive storage platform delivers unmatched surface stability, smooth item sliding, and flat support for delicate or loose parts. It is the premier choice for heavy industrial facilities, automotive parts distributors, and bulk staging zones needing maximum square footage per storage level.

Frequently Asked Questions

What are the primary performance advantages of particle board decking compared to wire mesh decking on boltless shelving?

Particle board decking provides a solid, flat, and uniform surface that prevents small parts, hardware, or loose items from tipping or falling through gaps. Its smooth surface allows heavy cardboard cartons, archive boxes, and plastic totes to slide effortlessly across the shelf during loading and retrieval. Additionally, high-density particle board offers an economical, rigid decking option that maximizes weight capacity per dollar for dry, temperature-controlled indoor storage environments.

What structural installation guidelines should be followed when setting up extra-wide 96-inch boltless shelving?

When assembling 96-inch wide boltless shelving, ensure all primary shoulder rivets are fully seated into the post keyhole slots by tapping the horizontal beams firmly with a heavy rubber mallet. Due to the extended 8-foot span, units carrying heavy payloads should utilize center support channels beneath the particle board decking to eliminate shelf deflection. For safety compliance, if the height-to-depth ratio exceeds 4:1, anchor the steel upright posts directly to the concrete floor slab or secure them to wall studs.

How do facility managers determine whether to use boltless rivet shelving versus selective pallet racking?

Boltless rivet shelving is engineered strictly for manual, hand-loaded inventory management, with typical shelf level capacities ranging between 600 and 1,500 lbs. It is ideal for carton picking, tool storage, and archive box staging. Selective pallet racking is designed for forklift-operated, palletized loads weighing thousands of pounds per bay. If inventory is moved by hand, boltless shelving provides far greater aisle efficiency, lower installation costs, and easier tool-free reconfiguration.
