wire decking
Wire Decking with 3 Channel Supports 2500 LBS Capacity 2Wire Decking with 4 channel supports 3200 LBS capacityInterlake Mecalux Pallet Rack Wire DeckingStep Style Wire DeckingWire Decking On Double Deep Pallet Rack Side AngleWire Decking UndersideWire Decking on Mecalux Pallet RackWire-Mesh-Decking-scaledWood Pallet on Wire Mesh DeckingWire Decking with 3 Step Channel Support on Pallet RackWire Mesh Decking in Double Deep Pallet RackingWire Mesh Decking in Double Deep Pallet RackWire Decking Interlake Pallet RackWire Mesh Decking Supports Wood PalletPallet Rack Wire DeckingWire-Decking-on-Interlake-Mecalux-Pallet-Rack-scaledWood Pallet on Wire Mesh Decking 2Pallet on Wire DeckingWire-Decking-StockLargest-Wire-Decking-Inventory-In-StockWire Decking Pic 1WRS Wire Deck Deck Spec Sheet

Wire Mesh Decking

MOST POPULAR SIZES OF WIRE MESH DECKING FOR PALLET RACK:

36″ d. x 46″ w. Wire decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 ga. wire grid. (3)- 16 ga. steel “Step Style” channel supports. Fits standard 1-5/8″ step beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 14 LBS. Part Number: 3646S3SC254046S00P

42″ d. x 46″ w. Wire decking. New. 2,000 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 GA. wire grid. (3)- 16 GA. steel “Step style” channel supports for standard 1-5/8″ step beams. 1″ waterfall on front & back. Gray powder coat finish. Weight: 16 LBS. Part Number: ND4246S3SC254046A00P

42″ d. x 46″ w. Wire Mesh Decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 GA. wire grid. (3)- 14 GA. steel “Step style” channel supports for standard 1-5/8″ step beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 18 LBS. Part Number: ND4246S3SA2504600P

42″ d. x 46″ w. Wire Mesh Decking. New. 3,000 lbs. capacity per pieces based on evenly distributed load. 2.5″ x 4″ x 6 GA. wire grid. (4)- 14 GA. steel “Step style” channel supports for standard 1-5/8″ step beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 18 LBS. Part Number: ND4246S4SA2504600P

42″ d. x 46″ w. Flared Wire decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 ga. wire grid. (3)- 14 ga. steel “Flared style” channel supports have universal fit for standard 1-5/8 step beams, box beams & structural c-channel beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 18 LBS. Part Number: ND4246F3FA254046S00P

42″ d. x 52″ w. Wire decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 ga. wire grid. (3)- 14 ga. steel “Step style” channel supports for standard 1-5/8″ step beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 19 LBS. Part Number: ND4252S3SA254046S00P

48″ d. x 46″ w. Wire Decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 ga. wire grid. (3)- 14 ga. steel “Step Style” channel supports for standard 1-5/8″ step beams. Fits standard 1-5/8″ step beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 21 LBS. Part Number: ND4846S3SA254046S00P

**SEE BELOW FOR COMPLETE LIST OF STANDARD / STOCK WIRE MESH DECKING SIZES. We can design pallet racking wire decking for almost any pallet rack system. Please call us at 800-763-9020 or email sales@rackandshelf.com. We would be happy to discuss your requirements and find a wire mesh deck size and style that fits your needs.

We stock wire decking for pallet racking in 22 different sizes and multiple styles. The most popular style is wire decking with step channel supports for standard 1-5/8″ step beams. We also stock wire decking with flared channel supports for a more universal fit. Wire decking with flared style channel supports will fit step beams, box beams and structural channel beams – almost any beam. We also stock warehouse wire decking with Inside Waterfall (no waterfall) and wire mesh decking with inverted channel supports (turned upside down so dirt dust and dirt cannot gather) which is popular in the food distribution industry.

NOTES: MIN. ORDER QTY: 4 PCS. Stated capacities are based on (UDL) uniform distributed loads. Warehouse wire decking in stock, allow est. 5-7 days to ship. Ships best way pre-paid & add. Freight Class 50.  FOB: Chicago, IL, Williamsport, PA, Charlotte, NC, Dallas, TX, San Bernardino, CA and Seattle, WA

Lower Prices for Larger Quantities

Low cost warehouse wire mesh decking has so many advantages, it sells itself!

Wire mesh decking can totally transform your pallet racking system! The pallet rack is already a diverse system, but wire decking can give you even more flexibility in your storage options. If you’ve been looking for a way to transform your storage system without breaking the bank, wire decking could be a great option for you!

The greatest advantage to wire decking for pallet racks is that it offers you a tremendous amount of flexibility and versatility in what you can store on your racks. With warehouse wire decking, you can store everything from boxes, to bins to full pallet loads. In fact, wire decking for pallet racks can be designed to support almost any load, except for point load applications. Wire decking for pallet racks get the majority of its capacity from its channel supports. Therefore loads must be evenly distributed over U-channel supports.

Warehouse wire decking makes it easy to store full pallet loads, bins, boxes and more. The design of the wire decking allows you to store a variety of inventory safely and all in the same place. Because the design is mesh, staff is able to clearly see the inventory, which cuts down on valuable time spent moving inventory to find a specific SKU. The channel supports give the wire decking its capacity. It’s important to note that loads need to be distributed evenly to avoid overloading a shelf.

We’re committed to supplying ISO 9000 quality wire mesh decking for pallet racks. We have the lowest prices on high quality, lightweight, heavy-duty welded warehouse wire decking. Our step deck is recognized for its superior strength, quality and exceptional value. Custom designable, our warehouse wire decking for pallet racks is made to fit the specific depth, length and load capacity of your rack system.

Warehouse Rack & Shelf offers the world’s largest inventory of standard waterfall wire decking for pallet racks. You can find wire shelving in Los Angeles, for example, and even more products nation-wide! With over 100,000 wire decks in stock nationwide, we can ship in 48 hours from four stocking locations. To save you money on freight, we offer strategically located stocking facilities in St. Louis, MO, Chicago, IL, Williamsport, PA, Charlotte, NC, Dallas, Texas, San Bernardino, CA and Seattle, WA.

Please call us at 800-763-9020 to discuss your requirements with one of our friendly and knowledgeable salespeople. You may also email us at sales@rackandshelf.com. We’ll send you a prompt quotation. It’s our objective to offer you the highest quality warehouse wire decking for pallet racks, at the lowest price with exceptional customer service.

Standard wire mesh decking description:
42″ d. x 46″ w. Wire decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 ga. wire grid. (3)- 14 ga. steel “Step style” channel supports. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 18.4 LBS. Part Number: 4246S3SA254046S00P

Advantages of wire mesh decking for pallet racks include:
• Allows you flexibility in what you store on your rack
• Safely supports your pallet loads and prevent them from falling to the floor
• Decrease fire hazard: Non-flammable wire decking solution replaces wood decking in your racks. Allows water to flow from overhead sprinklers
• Meets Fire Marshall’s requirements. In many cases can reduce insurance rates
• Easy drop-in installation
• Sanitary: self-cleaning: dust and dirt will not build up on wire mesh
• Low maintenance: Doesn’t require cleaning
• Better illumination of product: Light absorbs through wire mesh to give workers better view of product. Improved visibility allows easier inventory
• Improve storage efficiency: Reduce load time by giving forklift driver confidence in setting down pallets at high elevations

COMPLETE LIST OF STOCK SIZES AND PART NUMBERS (F in Part Number = Flared Channel, S in Part Number = Step Channel):

24″ x 46″ Wire Deck-Flared Channel ND2446F3FC254046S00P 9.4
30″ x 46″ Wire Deck-Flared Channel ND3046F3FC254046S00P 11.4
36″ x 46″ Wire Deck-Flared Channel ND3646F3FC254046S00P 13.8
36″ x 46″ Wire Deck-Step Channel ND3646S3SC254046S00P 13.8
36″ x 52″ Wire Deck-Step Channel ND3652S3SC254046S00P 14.8
36″ x 58″ Wire Deck-Step Channel ND3658S4SC254046S00P 17.5
42″ x 46″ Wire Deck-2,500lb Flared ND4246F3FA254046S00P 17.5
42″ x 46″ Wire Deck-3,500lb Flared ND4246F4FA254046S00P 20.4
42″ x 46″ Wire Deck-2,500lb Step ND4246S3SA254046S00P 17.4
42″ x 46″ Wire Deck-2,000lb Step ND4246S3SC254046A00P 15.6
42″ x 46″ Wire Deck-Inside Waterfall ND4246S4SC254046I00P 16.1
42″ x 46″ Wire Deck-3,500 LB Step ND4246S4SA254046S00P 20.0
42″ x 52″ Wire Deck-Flared Channel ND4252F3FA254046S00P 18.9
42″ x 52″ Wire Deck-2,500LB Step ND4252S3SA254046S00P 18.6
42″ x 52″ Wire Deck-3,500LB Step ND4252S4SA254046S00P 21.1
42″ x 58″ Wire Deck-Step Channel ND4258S4SC254046S00P 20.1
44″ x 46″ Wire Deck-Flared Channel ND4446F3FA254046S00P 18.4
44″ x 46″ Wire Deck-2,500LB Step ND4446S3SA254046S00P 18.4
44″ x 52″ Wire Deck-2,500LB Step ND4452S3SA254046S00P 19.7
44″ x 58″ Wire Deck-2,500 LB Step ND4458S4SC254046S00P 21.3
48″ x 46″ Wire Deck-Flared Channel ND4846F3FA254046S00P 20.1
48″ x 46″ Wire Deck-2,500LB Step ND4846S3SA254046S00P 20.1
48″ x 46″ Wire Deck-3,000LB Step ND4846S4SA254046S00P 23.0
48″ x 52″ Wire Deck-2,500LB Step ND4852S3SA254046S00P 21.4
48″ x 58″ Wire Deck-3,000LB Step ND4858S4SA254046S00P 25.7
60″ x 46″ Wire Deck-2,500LB Step ND6046S4SA254046S00P 28.7

Additional Information

Weight lbs
Dimensions N/A
Sizes

24″ d. x 46″ w. Wire decking. Flared channel. 2,500 lbs capacity (UDL). PN. 2446F3FC254046S00P, 30″ d. x 46″ w. Wire decking. Flared Channel. 2,500 lbs. capacity (UDL). PN. 3046F3FC254046S00P, 36″ d. x 46″ w. Wire decking. Flared channel. 2,500 lbs. capacity (UDL). PN 3646F3FA254046S00P, 36″ d. x 46″ w. Wire decking. Step channel. 2,500 lbs. capacity (UDL). PN. 3646S3SC254046S00P, 36″ d. x 52″ w. Wire decking. Step channel. 3,000 lbs. capacity (UDL). PN. 3652S3SC254046S00P, 36″ d. x 58″ w. Wire decking. Step Channel. 3,000 lbs. capacity (UDL). PN. 3658S4SC254046S00P, 42″ d. x 46 w. Wire decking. Step channel. 3,500 lbs. capacity (UDL). PN. 4246S4SA254046S00P, 42″ d. x 46″ w. INSIDE WATERFALL Wire decking. 2,500 lbs. capacity (UDL). PN. 4246S4SC254046I00P, 42″ d. x 46″ w. INVERTED CHANNEL Wire decking. 3500 lbs. capacity (UDL). PN. 4246S4IA254046, 42″ d. x 46″ w. Wire decking. Flared channel. 2,500 lbs. capacity (UDL). PN. 4246F3FA254046S00P, 42″ d. x 46″ w. Wire decking. Step channel. 2,000 lbs. UDL. PN. 4246S3SC254046A00P, 42″ d. x 46″ w. Wire decking. Step Style. 2,500 lbs. cap. (UDL) PN 4246S3SA254046S00P, 42″ d. x 52″ w. Wire decking. Flared channel. 2,500 lbs. capacity (UDL). PN. 4252F3FA254046S00P, 42″ d. x 52″ w. Wire decking. Step Channel. 2,500 lbs. capacity (UDL). PN. 4252S3SA254046S00P, 42″ d. x 52″ w. Wire decking. Step channel. 3,500 lbs. capacity (UDL). PN. 4252S4SA254046S00P, 42″ d. x 58″ w. Wire decking. Step channel. 2,500 lbs. capacity (UDL). PN. 4258S4SC254046S00P, 44″ d. x 46″ w. Wire decking. Flared channel. 2,500 lbs. capacity (UDL) PN. 4446F3FA254046S00P, 44″ d. x 46″ w. Wire decking. Step style. 2,500 lbs. capacity (UDL). PN. 4446S3SA254046S00P, 44″ d. x 52″ w. Wire decking. Step channel. 2,500 lbs. capacity (UDL). PN. 4452S3SA254046S00P, 48″ d. x 46″ w. Wire decking. Flared channel. 2,500 lbs. capacity (UDL). PN. 4846F3FA254046S00P, 48″ d. x 46″ w. Wire decking. Step channel. 2,500 lbs. capacity (UDL). PN. 4846S3SA254046S00P, 48″ d. x 46″ w. Wire decking. Step channel. 3,000 lbs. capacity (UDL). PN 4846S4SA254046S00P, 48″ d. x 52″ w. Wire decking. Step channel. 2,500 lbs. capacity (UDL). PN. 4852S3SA254046S00P, 48″ d. x 58″ w. Wire decking. Step channel. 3,000 lbs. capacity (UDL). PN. 4858S4SA254046S00P, 60″ d. x 46″ w. Wire decking. Step channel. 2,500 lbs. capacity (UDL). PN. 6046S4SA254046S00P

Click on a product title below to view more details.

Wire Decking with Step Channel Supports

Wire Decking-with-Step-Channel-Supports

42″ d. x 46″ w. Wire decks. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 GA wire  grid. (3)- 14 GA steel “Step style” channel supports. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 17.4 LBS. Part Number: 4246S3A254046 *NOTE: THIS IS OUR MOST POPULAR WIRE DECK. IT’S ALSO THE MOST COMMON. IT IS DESIGNED TO FIT ON A STANDARD 1-5/8″ PALLET RACK STEP BEAM.

NOTES: In stock, allow est. 5-7 days to ship. Ships best way pre-paid & add. Freight Class 50. FOB: Chicago, IL 60446, Atlanta, GA 30297, Dallas, TX 75228 and Los Angeles, CA 92408

Read more

get a step channel wire decking quote Lower Prices for Larger Quantities

Flared Channel Wire Decking | Universal Fit Pallet Rack Decking

Flared Channel Wire Decking

42″ d. x 46″ w. FLARED Wire decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 GA wire  grid. (3)- 14 GA steel “Flared style” channel supports. Has a Universal Fit that fits standard 1-5/8 step beams, box beams & structural channel beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 17 LBS. Part Number: 4246F3FA254046

NOTES: In stock, allow est. 5-7 days to ship. Ships best way pre-paid & add. Freight Class 50.  FOB: Chicago, IL 60446, Atlanta, GA 30297, Dallas, TX 75228 and Los Angeles, CA 92408

Read more

get a flared channel wire decking quote Lower Prices for Larger Quantities

Inside Waterfall Wire Decking | Wire Decking with No Waterfall for Clean Beam Face

Inside-Waterfall-Wire-Decking

42″ deep x 46″ wide Inside Waterfall Wire Decking. New. 2.5″ x 4.0″ mesh, 6 ga wire. 4 – inverted step channels (16ga), Inside Waterfall (NO WATERFALL). Powder Coat Finish. Weight: 17 LBS. Part Number: ND4246S4IC254046I00P

NOTES: Est. Lead Time: 8-10 weeks. Ships best way pre-paid & add. Freight Class 70. FOB: Chicago, IL 60446, Atlanta, GA 30297, Dallas, TX 75228 and Los Angeles, CA 92408

Read more

get an inside waterfall wire decking quote Lower Prices for Larger Quantities

Inverted Channel Wire Decking for the Food Distribution Industry

Inverted Channel Wire Decking

42″ d. x 46″ w. INVERTED CHANNEL wire decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 GA wire  grid. (3)- 14 GA steel “INVERTED” step style channel supports for standard 1-5/8 step beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 17 LBS. Part Number: ND4246S3IA254046S00P

*Inverted means that the channel supports that are welded to the bottom of the wire deck have been turned upside down. These Inverted Channel wire decks are popular in the food distribution industry because the inverted channels don’t allow for dirt and debris to build up in the channels of the wire deck. They are self cleaning.

NOTES: This is a custom wire deck with an estimated 8-10 weeks lead time (production). Ships best way pre-paid & add. Freight Class 70. FOB: Chicago, IL 60446, Atlanta, GA 30297, Dallas, TX 75228 and Los Angeles, CA 92408

Read more

get an inverted channel wire decking quote Lower Prices for Larger Quantities

Inverted Flared Wire Decking | Universal Fit For The Food Industry

Inverted Flared Wire Decking

42″ d. x 46″ w. INVERTED FLARED Wire decking. New. 2500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4.5″ x 4 GA wire grid. (3)- 14 GA steel “Inverted Flared Style” channel supports. Flared channel offers a Universal Fit that works with standard 1-5/8″ step beams, box beams & structural channel beams. 1-1/2″ waterfall on front & back. Gray powder coat finish. Weight: 25 LBS. Part Number: ND4246F3IA254046S00P

*Inverted for wire shelving systems means that the channel supports that are welded to the bottom of the wire deck have been turned upside down. These Inverted Channel wire decks are popular in the food distribution industry because the inverted channels don’t allow for dirt and debris to build up in the channels of the wire deck. They are self cleaning.

NOTES: This is a custom wire deck with an estimated 8-10 weeks lead time (production). Ships best way pre-paid & add. Freight Class 70. FOB: Chicago, IL 60446, Atlanta, GA 30297, Dallas, TX 75228 and Los Angeles, CA 92408

Read more

get an inverted flared wire decking quote Lower Prices for Larger Quantities

Reverse Waterfall Wire Decking

Reverse Waterfall Wire Decking

42″ d. x 46″ w. REVERSE WATERFALL wire mesh decking. New. 2,500 lbs. capacity per piece based on evenly distributed load. 2.5″ x 4″ x 6 GA wire  grid. (3)- 14 GA steel “Step Style” channel supports for standard 1-5/8 step beams. 1-1/2″ waterfall down on front & waterfall up in the back. Gray powder coat finish. Weight: 17 LBS. Part Number: ND4246S3SA254046SR15P

*Reverse Waterfall means that instead of the 1-1/2″ waterfall facing downward in the back it faces upward and creates a stop. This reverse wire rack decking is popular in the warehousing industry because it keeps boxes from falling of the back of the rack.

NOTES: This is a custom wire deck with an estimated 8-10 weeks lead time (production). Ships best way pre-paid & add. Freight Class 70. FOB: Chicago, IL 60446, Atlanta, GA 30297, Dallas, TX 75228 and Los Angeles, CA 92408

Read more

get a reverse waterfall wire decking quote Lower Prices for Larger Quantities

Flat Wire Decking For Boltless Shelving

Flat-wire-decking-9

NOTES: Flat Wire Decking is In stock, allow est. 5-7 days to ship. Ships best way pre-paid & add. Freight Class 50.  FOB: Chicago, IL 60446, Omaha, NE 68131 or Frankfort KY 40601 *Warehouse Rack & Shelf recommends the use of shelf supports with flat decks

Read more

get a flat wire decking quote Lower Prices for Larger Quantities

Click on a product title below to view more details.

Snap-In Wire Dividers for Wire Decking

Snap-in-Wire-Divider-for-Pallet-Rack

34″ d. x 12″ h. Snap-in Vertical Wire Shelf Dividers. New. Gray Powder Coat Finish. Weight: 3 LBS. Part Number: 3412K *FOR 36″ DEEP WIRE DECKING.

40″ d. x 12″ h. Snap-in vertical wire shelf dividers. New. Gray powder coat finish. Weight: 4 LBS. Part Number: 4012K *FOR 42″ DEEP WIRE DECKING.

46″ d. x 12″ h. Snap-in vertical wire shelf dividers. New. Gray powder coat finish. Weight: 5 LBS. Part Number: 4612K *FOR 48″ DEEP WIRE DECKING.

*MINIMUM ORDER QUANTITY 20 PCS.

NOTES: THESE SNAP-IN DIVIDERS ARE ONLY GUARANTEED TO FIT OUR WIRE DECKING. WE CANNOT GUARANTEE THAT THESE SNAP IN WIRE DIVIDERS WILL FIT OTHER MANUFACTURES WIRE DECKING. IT MAY BE WISE TO PURCHASE SAMPLES BEFORE ORDERING A LARGE QUANTITY. In stock, allow est. 5-7 days to ship. Ships best way pre-paid & add. Freight Class 50.  FOB: Nashville, TN 37218

Read more

get a snap-in wire divider quote Lower Prices for Larger Quantities

Hanging Wire Dividers For Pallet Rack

Hanging-Wire-Shelf-Dividers-400×299

42″ D. x 20″ H. (28″ Overall Height with Hooks) Hanging wire shelf dividers. New. 2″ x 4″ x 6 GA mesh. Gray powder coat finish. ***NOTE: TOP OF BEAM TO TOP OF BEAM DIMENSION IS 40″. DEPTH OF RACK IS 42″. Weight: 8 LBS. Part Number: WD-4442-20-Hang ***BUILT TO ORDER/ SPEC SHEET REQUIRED.

NOTES: 20 PC MINIMUM ORDER QUANTITY. We do not stock hanging rack dividers. Custom hanging wire dividers require a 8-10 week lead time. If you want a hanging wire divider quote please fill out attached hanging rack divider specification sheet or ANSWER 3 QUESTIONS BELOW. Ships FOB: Chicago, IL, Watsontown, PA, Charlotte, NC, Dallas, TX, San Bernardino, CA or Seattle, WA.

Read more

get a hanging wire divider quote Lower Prices for Larger Quantities

• 24″ d. x 46″ w. Wire decking. New. 3,000 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Flared Channels. ND2446F3FC254046S00P
• 30″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Flared Channels. ND3046F3FC254046S00P
• 36″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Flared Channels. ND3646F3FC254046S00P
• 36″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND3646S3SC254046S00P
• 36″ d. x 52″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND3652S3SC254046S00P
• 36″ d. x 58″ w. Wire decking. New. 3,000 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 4 Step Channels. ND3658S4SC254046S00P
• 42″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Flared Channels. ND4246F3FA254046S00P
• 42″ d. x 46″ w. Wire decking. New. 2,000 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels (1” waterfall). ND4246S3SC254046A00P
• 42″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND4246S3SA254046S00P
• 42″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 4 INSIDE WATERFALL Channels. ND4246S4SC254046I00P
• 42″ d. x 52″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Flared Channels. ND4252F3FA254046S00P
• 42″ d. x 52″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND4252S3SA254046S00P
• 42″ d. x 52″ w. Wire decking. New. 3,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 4 Step Channels. ND4252S4SA254046S00P
• 42″ d. x 58″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 4 Step Channels. ND4258S4SC254046S00P
• 44″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Flared Channels. ND4446F3FA254046S00P
• 44″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND4446S3SA254046S00P
• 44″ d. x 52″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND4452S3SA254046S00P
• 48″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Flared Channels. ND4846F3FA254046S00P
• 48″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND4846S3SA254046S00P
• 48″ d. x 46″ w. Wire decking. New. 3,000 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 4 Step Channels. ND4846S4SA254046S00P
• 48″ d. x 52″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 3 Step Channels. ND4852S3SA254046S00P
• 48″ d. x 58″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 4 Step Channels. ND4858S4SA254046S00P
• 60″ d. x 46″ w. Wire decking. New. 2,500 LBS. cap./pc. 2.5″ x 4″ x 6 GA mesh. 4 Step Channels. ND6046S4SA254046S00P
*All stocked decks come standard with a 1.5” front/rear waterfall and a powder coat gray finish. Optional galvanized after weld finish is available upon request.
**All capacities (lbs.) are based on uniform distributed loads.
